Titanium sheets are widely used across various industries due to their exceptional strength, lightweight properties, and corrosion resistance. Our company offers a full range of titanium sheets in multiple grades and sizes, ensuring suitability for diverse applications such as aerospace, medical, marine, and industrial sectors.


Available Grades of Titanium Sheets & Their Chemical Composition

Titanium sheets are widely used across various industries due to their exceptional strength, lightweight properties, and corrosion resistance. Our company offers a full range of titanium sheets in multiple grades and sizes, ensuring suitability for diverse applications such as aerospace, medical, marine, and industrial sectors.

Grade

Titanium (Ti)

Aluminum (Al)

Vanadium (V)

Palladium (Pd)

Molybdenum (Mo)

Nickel (Ni)

Oxygen (O)

Nitrogen (N)

Hydrogen (H)

Carbon (C)

Iron (Fe)

Grade 1

99.5%

-

-

-

-

-

≤ 0.18%

≤ 0.03%

≤ 0.015%

≤ 0.08%

≤ 0.20%

Grade 2

99.2%

-

-

-

-

-

≤ 0.25%

≤ 0.03%

≤ 0.015%

≤ 0.08%

≤ 0.30%

Grade 3

99.1%

-

-

-

-

-

≤ 0.35%

≤ 0.05%

≤ 0.015%

≤ 0.08%

≤ 0.30%

Grade 4

99.0%

-

-

-

-

-

≤ 0.40%

≤ 0.05%

≤ 0.015%

≤ 0.08%

≤ 0.50%

Grade 5 (Ti-6Al-4V)

Balance

5.5-6.75%

3.5-4.5%

-

-

-

≤ 0.20%

≤ 0.05%

≤ 0.015%

≤ 0.08%

≤ 0.40%

Grade 7

Balance

-

-

0.12-0.25%

-

-

≤ 0.25%

≤ 0.03%

≤ 0.015%

≤ 0.08%

≤ 0.30%

Grade 9 (Ti-3Al-2.5V)

Balance

2.5-3.5%

2.0-3.0%

-

-

-

≤ 0.15%

≤ 0.03%

≤ 0.015%

≤ 0.08%

≤ 0.25%

Grade 12

Balance

-

-

-

0.2-0.4%

0.6-0.9%

≤ 0.25%

≤ 0.03%

≤ 0.015%

≤ 0.08%

≤ 0.30%

Applications of Titanium Sheets in Different Industries

Titanium sheets are widely used across various industries due to their unique properties. Below are the typical applications of different grades:

Grade

Industry

Applications

Grade 1

Chemical Processing, Marine, Medical

Heat exchangers, desalination plants, medical implants, architecture

Grade 2

Aerospace, Marine, Chemical

Aircraft components, piping systems, heat exchangers, pressure vessels

Grade 3

Power Generation, Industrial

Structural components, power plant equipment, high-stress applications

Grade 4

Medical, Aerospace, Sports

Medical implants, aircraft construction, bicycle frames

Grade 5 (Ti-6Al-4V)

Aerospace, Medical, Automotive

Jet engines, high-performance automotive parts, orthopedic implants

Grade 7

Chemical Processing, Marine

High-corrosion environments, desalination plants, chemical reactors

Grade 9 (Ti-3Al-2.5V)

Aerospace, Marine, Sports

Tubing, marine structures, bicycle components

Grade 12

Power Plants, Chemical, Marine

Heat exchangers, marine equipment, industrial applications


Applications of Titanium Sheets in Different Industries

We provide titanium sheets in a range of thicknesses and standard dimensions to suit different industry needs:

  • Thickness Range:  0.5 mm to 100 mm
  • Standard Dimensions:
    • 1000 x 2000 mm
    • 1250 x 2500 mm
    • 1500 x 3000 mm
    • Custom sizes available upon request


Conclusion

Titanium sheets offer unmatched strength, corrosion resistance, and lightweight properties, making them ideal for various industries. Whether you need sheets for aerospace, marine, medical, or industrial applications, we have the perfect solution to meet your needs.
For further inquiries or custom requirements, please contact us today!
